| This image shows a plan view of the entire stair system notice how you
can see all the railings from top to bottom. There are 2 intermittent
landings between the floor levels that are self supporting. This image
also show the use of goosenecks in succession. The illustration of the C1S
stringer configuration is accentuated showing the top view of the treads
with returns, notice the miters in the front right corner of the steps.
Also note the way the edge of the tread goes back behind the one above
it, and how the balusters sit down on the surface of each step. The
returns add a polished look to the tread edge instead of showing the end
growth of the wood if no return were present which may be desirable in a
more rustic setting.
-
if your browser supports the feature run your mouse around the image and
important details will become visible about the item
|
